Metals and alloys are some of the most widely used materials in manufacturing today due to their high strength, reliable properties, and processability. Metals and alloys are commonly used in construction, medical devices, small part manufacturing, and many other applications. Our NAT lab can perform alloy phase identification and element distribution analysis using scanning electron microscopy (SEM) and x-ray energy dispersive spectroscopy (EDS). We have an STA 449 F3 Jupiter Thermal Analyzer, which can perform differential scanning calorimetry (DSC) and thermogravimetric analysis (TGA) simultaneously. The Jupiter Thermal Analyzer can precisely measure the temperature of a phase transformation or decomposition up to 1650 °C.

Typical Experimental Results

SEM image of a Zinc-Aluminum alloy composed of a lamellar eutectic α phase (dendrite network) and a zinc-rich η phase.

Backscatter electron image of a Zinc-Aluminum alloy. The brighter regions are the Zinc rich phase, the dull gray regions are the Aluminum rich phase, and the black regions are voids within the casting.

SEM/EDS image of a cast Zinc-Aluminum part with Nickel and Chromium coatings.

Applications

Alloys Ceramics Chemical Etching Cross-Section Analysis Crystal Structures
Diffusion Layer Element Distribution Element Identification Failure Analysis Foreign Material Identification
Forensic Analysis Fractography Fracture Study Grain Boundaries Grain Growth
Grain Orientation Grain Size Grain Structure Grains IC Failure Analysis
Materials Metallography Metallurgy Metals Microscopy
Microstructure Phase Diagram Phase Distribution Steels Welds

For more information please read our application notes:

Identify Unknown Coating and Materials by Energy Dispersive SpectroscopyPDF

Micro Porosity Measurement of Zn-Al alloy Casting

Phase Identification and Distribution Analysis by Backscattered Electrons Imaging

Instruments: JEOL 6610 LV Scanning Electron Microscope

Key Specifications

Filament W hairpin filament
Resolution High Vacuum: 3nm (30kV),
8nm (3kV), 15nm (1kV)
Low Vacuum: 4 nm (30kV)
Accelerating Voltage 300 V to 30 kV
Magnification 5x to 300,000x
LV Detector Multi-segment BSED
LV Pressure 10 to 270 Pa
Sample Sizes Height: 80mm; Width: 178 mm
Stage Eucentric 5 axis motor control, asynchronous movement, x-y: 125mm-110mm, z: 5mm-8mm, tilt:-10 to 90 degrees, rotation: 360 degrees
Resolution 5120 x 3840 pixels
Condenser Lens Zoom condenser lens
Objective Lens Conical objective lens
Identify Unknown Coating and Materials by Energy Dispersive Spectroscopy

Have some unknown samples? We can help you to determine what they are and where they came from.  X-ray Energy Dispersive Spectroscopy (EDS) is a semi-quantitative x-ray technique that can identify and measure chemical composition in SEM analysis. Figure 1 shows the principle of EDS. The SEM focuses an electron beam on the sample surface.  The electrons knock core-shell electrons out of atoms inside the sample.  To fill this vacancy, a higher energy electron from the atom will fall down to take its place, and the difference in energy between the two states is emitted as an x-ray.  The generated x-rays possess energies unique to the element which are dependent upon the atomic number (Z) and the orbital transition involved. Measuring the spectrum of emitted x-ray allows for chemical characterization of the sample.

Figure 1. A representation of the principle behind EDS.

this project, an automotive emblem of unknown composition was analyzed by SEM/EDS. EDS can measure the composition at a single point, along a line, or map an area. In this case, the chemical composition was analyzed by EDS area scanning following ASTM E1508 – 12a using an accelerating voltage of 15 kV, take-off angle of 35º, and sample tilt of 0º. The test was performed using a standardless method with P/B-ZAF matrix correction. Figure 2 shows a typical microstructure and the resulting EDS spectrum. Five randomly selected areas at 200X magnification were analyzed by EDS.

Figure 2. Typical microstructure and EDS spectrum result of unknown sample

Through EDS, we found that this sample is mainly composed of Zn with Al as an alloying element. The elemental concentrations were calculated by difference, and the K lines were selected to do the quantitative analysis. Table 1 lists the individual and average EDS results. The average concentrations of Zn and Al are 93.8 and 6.2 wt% respectively, which is a common composition for zinc die castings. Zn alloys have excellent finishing characteristics for plating, and chromate treatments. It is low cost, has excellent thin wall capabilities, and possesses high strength and hardness.

Table 1: Chemical compositions of an automotive emblem by EDS analysis

area 1 area 2 area 3 area 4 area 5 average
Zn (wt%) 92.0 94.8 94.2 94.0 94.1 93.8
Al (wt%) 8.0 5.2 5.8 6.0 5.9 6.2

EDS can also do high resolution composite element mapping. Through the element map, we can see a detailed overview of where the different elements are located. Figure 3 clearly indicates that there were three layers of coating on the emblem. The innermost layer in direct contact with the Zn-Al substrate was identified as Cu. The middle layer was Ni, and the outermost layer was Cr. This coating was likely prepared by an electroplating process where the Cu layer facilitated the formation of a good Ni coating. This is a common processing step for electroplating Ni onto cast metal parts. The thicknesses of the Ni and Cr coatings are approximately 20 and 2 µm, respectively.

Figure 3. Element mapping images of unknown sample’s coating.

ASTM Number

Title

Website Link

A247 – 06e1 Standard Test Method for Evaluating the Microstructure of Graphite in Iron Castings Link
A262 – 15 Standard Practices for Detecting Susceptibility to Intergranular Attack in Austenitic Stainless Steels Link
A763 – 93(2009) Standard Practices for Detecting Susceptibility to Intergranular Attack in Ferritic Stainless Steels Link
A802 – 95(2015) Standard Practice for Steel Castings, Surface Acceptance Standards, Visual Examination Link
A892 – 06 Standard Guide for Defining and Rating the Microstructure of High Carbon Bearing Steels Link
B276 – 05(2015) Standard Test Method for Apparent Porosity in Cemented Carbides Link
B487 – 85(2013) Standard Test Method for Measurement of Metal and Oxide Coating Thickness by Microscopical Examination of Cross Section Link
B578 – 87(2015) Standard Test Method for Microhardness of Electroplated Coatings Link
B657 – 05 Guide for Metallographic Identification of Microstructure in Cemented Carbides Link
B748 – 90(2016) Standard Test Method for Measurement of Thickness of Metallic Coatings by Measurement of Cross Section with a Scanning Electron Microscope Link
B796 – 02 Standard Test Method for Nonmetallic Inclusion Content of Powders Intended for Powder Forging (P/F) Applications Link
E1508 – 98(2008) Standard Guide for Quantitative Analysis by Energy-Dispersive Spectroscopy Link
E3 – 01(2007)e1 Standard Guide for Preparation of Metallographic Specimens Link
E340 – 00(2006) Standard Test Method for Macroetching Metals and Alloys Link
E381 – 01(2012) Standard Method of Macroetch Testing Steel Bars, Billets, Blooms, and Forgings Link
E384 – 09 Standard Test Method for Microindentation Hardness of Materials Link
E384 – 10e2 Standard Test Method for Knoop and Vickers Hardness of Materials Link
E407 – 07(2015)e1 Standard Practice for Microetching Metals and Alloys Link
E45 – 05e3 Standard Test Methods for Determining the Inclusion Content of Steel Link
E562 – 11 Standard Test Method for Determining Volume Fraction by Systematic Manual Point Count Link
E7 – 03(2009) Standard Terminology Relating to Metallography Link
E768 – 99(2010)e1 Standard Guide for Preparing and Evaluating Specimens for Automatic Inclusion Assessment of Steel Link
E930 – 99(2015) Standard Test Methods for Estimating the Largest Grain Observed in a Metallographic Section (ALA Grain Size) Link
ISO Number Title Website Link
209:2007 Aluminium and aluminium alloys — Chemical composition Link
3887:2017 Steels — Determination of the depth of decarburization Link
4499-1:2008 Hardmetals — Metallographic determination of microstructure — Part 1: Photomicrographs and description Link
4499-4:2016 Hardmetals — Metallographic determination of microstructure — Part 4: Characterisation of porosity, carbon defects and eta-phase content Link
5949:1983 Tool steels and bearing steels — Micrographic method for assessing the distribution of carbides using reference photomicrographs Link
643:2012 Steels — Micrographic determination of the apparent grain size Link
6872:2015 Dentistry — Ceramic materials Link
9220:1988 Metallic coatings — Measurement of coating thickness — Scanning electron microscope method Link
